QMark COS-E Fan-Forced Wall Heaters

Product Overview

Warm
up
single
rooms
and
small
spaces
quickly
using
a
QMark
COS-E
Fan-Forced
Wall
Heater.
Available
in
multiple
wattages
and
voltage
configurations,
these
electric
wall
heaters
—
manufactured
by
Marley
Engineered
Products
—
deliver
a
maximum
of
2,000
watts
of
heat
to
small
residential
areas.
Each
heater
is
designed
for
surface,
semi-recessed,
or
recessed
mounting
and
features
a
three-piece
design
to
simplify
installation.
These
impressive
wall
heaters
are
commonly
used
in
basements,
bathrooms,
hallways,
bedrooms,
and
remodels.

Pick
Your
Heating
Power

These
wall-mounted
heaters
are
wired
directly
into
your
wall.
Models
are
available
in
120-volt
and
240-volt
configurations.
Select
a
wattage
that
best
fits
your
space,
and
make sure
your
home
or
business
is
wired
for
the
corresponding
voltage:

•
  QMark
  CZ1512T
  Wall
  Heater:
  120-volts,
  Max
  CFM
  of
  65,
  1,500-watts,
  12.5-amp
•
  QMark
  CZ1012T Wall
  Heater:
  120-volts,
  Max
  CFM
  of
  65,
  1,000-watts,
  8.4-amp
•
  QMark
  CZ1548T Wall
  Heater: 240-volts,
  Max
  CFM
  of
  65,
  1,500-watts,
  6.3-amp
•
  QMark
  CZ2048T
  Wall
  Heater: 240-volts,
  Max
  CFM
  of
  65,
  2,000-watts,
  8.3-amp

Quick
Heat,
Low
Maintenance

QMark
COS-E
electric
wall
heaters
deliver
quick
and
powerful
heat
with
surprisingly
little
maintenance.
Each
heater
features
a
fast-response
heating
coil
that
heats
quickly
and
disperses
warmth
evenly
throughout
your
environment
with
the
help
of
a
permanently
lubricated,
completely
enclosed
fan.
A
built-in
double
pole
thermostat
with
a
control
knob
gives
you
complete
control
over
heat
output.
In
addition,
each
heater’s
front
display
cover
is
constructed
with
rugged
stamped
steel
to
help
protect
internal
components
and
direct
airflow
through
louvers.

Patented
Clip-N-Fit
Function

To
give
you
more
control
over
the
heater’s
energy
use
and
more
flexibility
in
installation,
these
QMark
heaters
are
equipped
with
patented
Clip-N-Fit
controls.
This
function
allows
you
to
adjust
the
wattage
of
the
heater
to
a
lower
output
without
moving
the
jumper
wire.
Each
electric
wall
heater
is
factory
wired
for
its
maximum
wattage.
However,
you
may
want
to
adjust
the
wattage
to
suit
certain
installation
scenarios
and
household
power
usage
requirements.
For
example,
in
ceiling
mount
installations,
the
heater
should
be
modified
to
produce
a
maximum
of
1,000
watts.
To
change
the
wattage
of
the
heater,
simply
clip
out
either
jumper
1
or
2
following
the
chart
listed
in
your
installation
manual.

Safety
Functions

Each
QMark
wall
heater
is
UL-listed
and
includes
a
number
of
safety
features
designed
to
ensure
worry-free
operation.
To
protect
against
overheating
accidents,
a
thermal
cutout
with
an
indicator
light
disconnects
power
and
resets
the
heater
in
the
event
of
an
airflow
blockage.
A
one-time
thermal
fuse
also
cuts
power
in
case
of
a
more
serious
malfunction.
These
heaters
may
be
wired
using
standard
60-degree
Celsius
wiring
for
heat-sensitive
protection.

Installation
Tips

• The
  optimum
  height
  for
  each
  wall
  heater
  is
  18
  to
  24
  inches
  from
  the
  floor
  to
  the
  bottom
  of
  the
  backbox.
• Do
  not
  install
  the
  heater
  backbox
  closer
  than
  4.5
  inches
  from
  the
  floor
  or
  adjacent
  walls
  and
  closer
  than
  12
  inches
  from
  the
  ceiling.
• Do
  not
  install
  the
  heater
  behind
  a
  towel
  rack
  or
  door;
  in
  a
  floor
  or
  closet;
  or
  where
  airflow
  may
  be
  obstructed.
• To
  ensure
  proper
  operation,
  maintain
  5
  feet
  of
  minimum
  clearance
  to
  furniture
  or
  other
  objects
  placed
  directly
  in
  front
  of
  the
  heater.
• Multiple
  fan-forced
  models
  can
  be installed
  in
  larger
  rooms
  and
  controlled
  by
  a
  single
  thermostat.
  For
  this
  configuration,
  be
  sure
  to
  determine
  optimum
  wattage
  levels
  using
  heat
  loss
  calculations.
  As
  a
  general
  rule
  of
  thumb
  for
  primary
  heating,
  use
  10
  watts
  of
  heat
  per
  square
  foot
  of
  space.

Qmark COS-E
Dimensions

• Each
  model
  has
  the
  following
  dimensions:
  12
  inches
  high
  and
  9
  inches
  wide.
  Including
  the
  front
  panels,
  they’re
  also
  5
  inches
  deep.

Summary

Instantly
warm
any
space
with
the QMark
COS-E
Fan-Forced
Wall
Heater,
featuring
a
fast-response
heating
coil
and
patented
Clip-N-Fit
controls
for
adjusting
the
wattage
and
output

What
Customers
Love

•
  Quiet
  Operation
  –
  Quietly
  warms
  up
  any
  space
  without
  annoying
  reverberations
  or
  rattling.

Things
to
Consider

•
  Wired
  Into
  Wall
  –
  Heater
  is
  directly
  wired
  and
  installed
  into
  the
  wall.
